Creating surprising effects
PREFA rhomboid façade tiles in the large 44 × 44 cm format add surprising touches to the tried and tested “scaly” appearance of buildings. The fascinating rhomboid shape creates a contemporarily-styled façade which emphasizes the overall design and makes every building unique and full of character. The integrated fastening strips facilitate speedy and inexpensive installation of the façade elements.
- Visually coordinated design
- New mounting system — integrated fastening strip facilitates speedy installation
- System optimisation
- Available in 10 standard colours
Colour overview (11)
The product is available in the following colours
Colour |
Code |
~ RAL |
|
P.10 brown |
7013 |
|
P.10 anthracite |
7016 |
|
P.10 black |
9005 |
|
P.10 brick red |
8004 |
|
P.10 oxide red |
3009 |
|
P.10 moss green |
6005 |
|
P.10 light grey |
7005 |
|
P.10 prefa white |
9002 |
|
P.10 nut brown |
8019 |
|
P.10 dark grey |
7043 |
|
P.10 stone grey |
7031 |
Notes
- The RAL values stated are merely approximate values (~), some of which may differ vastly from the original PREFA colour and, under certain circumstances, may not reflect the subjective perception of the colour.
- Above all for colour quality P.10, it is almost impossible to define values due to the surface structure.
- Plain aluminium: The guarantee does not cover surface appearance alterations caused by processing and environmental influences. Follow the instructions.
- Metallic colours may vary in shade.
- To identify exact colours for complementary components please consult original samples.
Rhomboid façade tile 44 × 44 — Technical information
- Colour range: 10 standard colours — stucco finish
- also available with a smooth finish upon request
Technical information about the product
Material |
coil-coated aluminium, 0.7 mm thick |
|---|---|
Dimensions |
437×437 mm (cover), i.e. approx. 5 pc./m² |
Weight |
approx. 2.6 kg/m² |
Supporting substrate* |
on fully boarded substrate (at least 24 mm)* * Observe country-specific standards and specialist guidelines. |
Standard fastening |
direct fastening, 4 PREFA ring nails per rhomboid façade tile 44×44 (i.e. 20 PREFA ring nails per m²) |
Rhomboid façade tile 44 × 44 – Planning and installation
More product information is available for download here.
Note: Download DWG and DXF format files by right-clicking and selecting “Save link as”.
Accessories
Leading plate for rhomboid façade tile 44 × 44
-
End plate for rhomboid façade tile 44 × 44
-
Starter strip façade
for façade shingles, rhomboid façade tiles and FX.12; 1800 × 158 × 1,00 mm, pre-drilled
Fastener (metal screw)
for Sidings on an aluminium supporting substrate
Befestigungsmittel (Stahlschraube)
Spezialschraube für Stahl-Unterkonstruktionen, mit gehärteter Bohrspitze (rote Spitze nur zur Veranschaulichung)
